A construction contractor in Poland recently purchased a Mini Crawler Crane for Sale from YG Machinery. The 3-ton mini spider crane has already been shipped, along with a vacuum glass lifter attachment.
WhatsApp/WeChat/Phone: 86 138 3715 9132
Product Parameters of YG Mini Crawler Crane for Sale
| Model | YG-3 | |
| Specification | 3t | |
| Maximum working radius | 8.83m×0.15t | |
| Maximum above-ground head | 9.9m×0.7t | |
| Winch device | Hook Speed | 12m/min(4 rope) |
| Rope diameter | Φ11mm×80m | |
| Telescopic system | Boom Type | 5-section boom, pentagonal structure |
| Boom Length/Time | 12.3m/54sec | |
| Up and down | Boom Angle/Time | 0°~78°/13sec |
| Slew system | Slew Angle/Speed | 0-360°continuous/38sec |
| Traction system | Walking Way | Hydraulic motor drives |
| Walking Speed | 0~2.5km/h | |
| Grade Ability | (25°)36% | |
| Operating system | Operation type (Boom/outrigger) | Manual operation, manual walking(remote control option) |
| Operating characteristics | Manual operation, remote control | |
| Transport parameters | L*W*H(mm) | 5000*1600*2180 |
| Total weight(kg) | 7200 | |
Client Background: Polish Interior Contractor Needs Compact Lifting Tools
The buyer is a medium-sized interior finishing contractor in Warsaw who recently secured a contract to install glass curtain walls in a commercial building. Due to the narrow work area, traditional lifting machinery could not access the site.
While searching online for a compact solution, the client found our Mini Crawler Crane on Google. Intrigued by its lifting performance and narrow chassis, he contacted our sales team. After detailed communication with our product engineers, he decided to visit our China-based factory for a hands-on demonstration.
During his visit:
- He observed a full operation of the crane, including wireless remote control.
- He inspected the quality of hydraulic components and the structure.
- He tested our glass vacuum lifter in combination with the crane.
Impressed by the product’s performance and reliability, he immediately placed an order for one unit of the 3-ton mini spider crane and one vacuum suction system.
Mini Spider Crane Use Cases
- Indoor Glass Curtain Wall Installation
The crane operates inside a commercial lobby with a tight ceiling height. Its compact size allows easy entry through standard doors, and its telescopic boom provides enough reach for vertical glass placement. - Residential Balcony Glass Panel Mounting
In high-rise apartment projects, the crane lifts and positions heavy glass panels on balconies without the need for scaffolding or tower cranes. - Historic Building Maintenance
In renovation work, especially in older urban areas, the crane’s low ground pressure and compact footprint allow it to be used without damaging pavements or tiles. - These scenarios highlight how the Mini Crawler Crane adapts to specialized urban work conditions.
Mini Crawler Crane with Glass Lifter and Other Attachments
To maximize its utility, the Mini Crawler Crane can be combined with a range of practical accessories:
- Glass Vacuum Suction Pad System
- Designed for handling large glass panels
- Multiple suction cups with a battery-powered vacuum system
- Manual or electric tilting function for precision placement
- Fly Jib Attachment
- Extends the working range and reach
- Ideal for under-eaves or recessed installations
- Work Platform Basket
- Converts crane into a personnel lift for facade or maintenance work
These attachments provide versatility and reduce the need for multiple machines on site.
Safety Features Built Into the Spider Crane For Sale
Safety was a top concern for the Polish customer, and our spider crane for sale includes several mechanisms to ensure safe operation:
- Moment Limiter System – Automatically stops lifting if the load exceeds safe parameters
- Stability Control System – Ensures balance based on outrigger positioning
- Emergency Stop and Alarm System – Immediate shutdown in risky situations
- Wireless Remote Control – Keeps the operator at a safe distance from the load
- Manual Backup Pump – Ensures the crane can be retracted in the event of engine failure
These features help prevent accidents and ensure compliance with EU safety standards.
Why This Polish Client Chose YG Mini Crawler Crane
Several factors influenced the buyer’s decision to purchase our Mini Crawler Crane for Sale:
- Product Transparency – Full access to specifications, demo videos, and on-site testing
- Factory Visit Experience – Professional, hands-on demonstration and factory tour
- Technical Support – In-depth consultation and configuration advice
- Reasonable Pricing – Cost-effective compared to European and Japanese brands
- Customization Options – Compatibility with local safety standards and power preferences
With rising demand for folding cranes and mini spider cranes in Europe, the buyer recognized that YG Machinery could deliver both performance and value.
