What Is A Mortar Mixer And Spray Machine?
The Mortar Mixer and Spray Machine is a two-in-one unit designed to simplify wall coating tasks. It combines a mortar mixer and a spraying pump into a single system, allowing users to mix and spray plaster or mortar continuously. This machine excels at wet-spray applications, perfect for coating interior walls, exterior surfaces, and ceilings.
By automating both mixing and spraying, it saves labor, speeds up construction, and ensures a consistent finish.
WhatsApp/WeChat/Phone: 86 138 3715 9132
Mortar Mixer and Spray Machine Parameter
| Specification | Model 1 | Model 2 |
| Flow Rate | 3 m³/h | 0-60 L/min |
| Max Pressure | 6 MPa | 3 MPa |
| Material Ratio (Water:Cement: Sand) | 0.7–1:1:3 | 0.7–1:1:3 |
| Main Power + Mixing Power | 4 kW + 3 kW | 4 kW |
| Max Particle Size | ≤6 mm | ≤4 mm |
| Conveying Distance | Horizontal 40m / Vertical 20m | Horizontal 50m / Vertical 40m |
| Hopper Capacity | 60 L | 60 L |
| Air Compressor Flow Rate | 0.32 m³/min | 0.3 m³/min |
| Operating Voltage | 220-380 V | 220-380 V |
| Machine Weight | 360 kg | 360 kg |
Standard Configuration Of Mix Mortar Spray Equipment
This mix mortar spray equipment comes with a complete standard package to get you started immediately:
- 10m Mortar Spray Hose – Durable and easy to maneuver
- 10m Air Hose – Connects seamlessly to the integrated air compressor
- 1 Spray Gun – Ergonomic design for long-term operation
- 3 Spray Nozzles – For adjusting flow and spray pattern depending on the surface
The machine is easy to assemble and transport, making it a great choice for fast-paced job sites.
Key Features Of The Mortar Mixer And Spray Machine
The YG Mortar Mixer and Spray Machine is engineered for efficiency, durability, and ease of use. Its standout features include:
- Integrated Mixing and Spraying: Eliminates the need for separate machines
- Stable Output Pressure: Ensures uniform material application
- Lightweight and Portable: Easy to move between job sites
- User-Friendly Controls: Simple operation with minimal training
- Low Material Waste: Controlled spraying minimizes splatter
- Built-in Air Compressor: No external compressor required
Service Life Of The Machine
The Mortar Mixer and Spray Machine has an average working life of approximately 3,000 square meters under normal use conditions. Proper maintenance and correct material use can extend this machine’s lifespan.
Key factors affecting longevity include:
- Frequency of use
- Cleanliness after the operation
- Proper material mixture ratios
- Avoiding overloading during continuous spraying
Maintaining the internal pump and flushing the hoses after each job is key to maximizing performance and durability.
Price Factors For Mortar Mixing And Spraying Equipment
Several factors influence the price of mortar mixing and spraying equipment:
- Tank Capacity – Larger volume models are more expensive
- Pump Output Rate – Higher pressure and flow rate increase the cost
- Build Material – Stainless steel components last longer but cost more
- Level of Automation – Machines with self-cleaning or remote control functions cost more
- Included Accessories – Hose lengths, nozzle types, and spare parts can raise the total price
Balancing price with performance is important. Basic models are suitable for small projects, while high-end versions support continuous industrial work.
After-Sales Service From YG Machinery
YG Machinery offers full customer support for the Mortar Mixer and Spray Machine, including:
- 1-Year Warranty covering core components
- Free Online Training Videos and Manuals
- Spare Parts Supply to minimize downtime
- Fast Technical Support within 24 hours via phone or email
- Optional On-Site Service available in some regions
Our service ensures that contractors receive professional help throughout the equipment’s working life.
Special Notes For Safe And Effective Operation
Before using the Mortar Mixer and Spray Machine, it’s important to understand a few key technical notes:
- Dry Materials Not Allowed: The machine is designed for wet-spray only. Dry mortar may clog the pump.
- Built-In Compressor: No external air compressor is needed; it’s already included.
- Not For Concrete Spraying: Do not attempt to use concrete mix, which may damage internal components.
Following these guidelines helps ensure optimal function and prolongs machine life.
