A Reverse Circulation Drilling Rig is a machine used to drill and collect rock or soil samples. It is common in mineral exploration, geotechnical work, and deepwater well drilling. The rig uses reverse circulation drilling to bring cuttings straight to the surface inside an inner tube. This method reduces contamination and gives cleaner samples for analysis. The clean samples help geologists make better decisions.
How Reverse Circulation Drilling Works
Reverse circulation drilling uses two tubes inside the drill string. Drilling air or fluid pushes cuttings into the inner tube. The cuttings travel up the inner tube and come out at the surface. This keeps the sample free from drilling fluid and outside contamination. The process is fast and keeps the worksite cleaner.
WhatsApp/WeChat/Phone: 86 138 3715 9132
Key Components of RC drilling rig
A typical RC drilling rig includes:
- Drill mast and rotary head.
- Air compressor and dust collector.
- Feed system and rod handling.
- Inner and outer drill tubes.
- Control panel and safety devices.
Product Parameters of Reverse Circulation Drilling Rig for Sale
| Model | YG-300 | YG-600 | YG-1000 |
| Max drilling depth | 300m | 600m | 1000m |
| Drilling diameter | 105-305mm | 105-550mm | 105-800mm |
| Drill rod length | 3m | 6m | 6m |
| Driving efficiency | 10-35m/h | 10-35m/h | 10-35m/h |
| Weight | 11t | 17t | 23t |
| Dimensions | 6.2*1.85*2.8m | 10.5.*2.25*3.3m | 11.5*2.25*3.4 |
| In addition to the above models, customized drilling rigs and accessories are also supported. Some models and parameters will be updated; please refer to the actual quotation. | |||
Main Features Of Reverse Circulation Drilling Rig
The RC drilling rig for sale offers practical features that help field teams:
- High Sample Recovery
- Reverse circulation gives clean, uncontaminated samples.
- Better samples mean better lab results.
- Fast Drilling Speed
- Efficient removal of cuttings speeds up drilling.
- Projects finish sooner and cost less.
- Cost Efficiency
- Less re-drilling and faster sampling reduce overall cost.
- Low contamination lowers lab testing.
- Multi-Use Flexibility
- Suitable for mineral exploration drilling rig projects.
- Also used in water well drilling and geotech surveys.
Advantages In Field Use
Using a Reverse Circulation Drilling Rig brings clear field benefits:
- Samples are reliable for the assay and study.
- Machines work well in many ground types.
- Less waste and dust on site compared to open hole methods.
- Teams need fewer people to complete tasks.
Applications Of Reverse Circulation Drilling
Reverse circulation drilling is useful in many projects:
- Mineral Exploration
- Used to check gold, copper, and base metals.
- Good samples speed up resource estimation.
- Water Well Drilling
- Effective in deep, complex aquifers.
- Fast drilling helps reach water quickly.
- Geotechnical Drilling
- Used for soil and rock tests for building and road design.
- Other Uses
- Environmental sampling and some construction work.
Why Choose YG Reverse Circulation Drilling Equipment
When you look for Reverse circulation drilling equipment, YG offers clear advantages:
- Reliable Performance
- Built for hard work and long projects.
- Strong frames and quality parts for long life.
- High Drilling Efficiency
- Advanced air systems and rod handling increase speed.
- Inner tube design secures high sample return.
- Cost-Effective Solution
- Good price with low running costs.
- Less rework means better project margins.
- After-Sales Support
- YG provides installation, training, and spare parts.
- Remote support and field service help teams stay productive.
How To Choose The Right RC Drilling Rig
Pick a rig based on your project needs. Consider:
- Required drilling depth and hole size.
- Ground conditions (hard rock, sand, clay).
- Mobility needs (truck-mounted, trailer, or track-mounted).
- Power source and fuel availability.
- Payload for sample boxes and rod storage.
A clear checklist helps you select the best RC drilling rig for sale.
Ordering And Support From YG
To buy a YG Reverse Circulation Drilling Rig, follow these simple steps:
- Contact sales with project details: depth, hole size, and ground type.
- Get a tailored quote and model recommendation.
- Confirm order and delivery schedule.
- YG provides testing, packing, and shipping documentation.
- Receive the rig and get installation and operation training.
YG offers flexible delivery and spare parts packages. Technical support is ready to help with commissioning.
Case Example | Mineral Exploration Drilling Rig Project
A small mining company needed a rig to test a new prospect. They chose a YG RC rig. Results:
- Sample quality improved, enabling clear assay results.
- Drilling speed increased by 25%.
- Project costs dropped due to faster sampling and fewer repeat tests.
The customer praised the easy operation and quick support from YG.
Frequently Asked Questions
Q: Is reverse circulation good for all ground types?
A: It works well in hard and medium ground. In very soft ground, other methods may be better.
Q: How fast can an RC rig drill?
A: Speed varies by ground and rig size, but RC rigs are generally faster than conventional coring rigs.
Q: Do you provide spare parts and training?
A: Yes. YG supplies spare parts, training, and remote technical help.
