Water Well Drilling Truck

The Water Well Drilling Truck is a piece of equipment for obtaining clean and reliable water sources. It provides a mobile and efficient solution for drilling and extracting groundwater. The water well drilling truck is installed on a truck chassis and has both mobility and deep hole drilling capabilities. It is an ideal choice for various drilling operations, including domestic water wells, agricultural irrigation, and industrial water.

WhatsApp/WeChat/Phone: 86 138 3715 9132

Parameters of Water Well Drilling Truck

Model	YG-200	YG-300	YG-400	YG-600
Weight(Ton)	5.5	9	10	12
Drilling Diameter(mm)	140~305	140~325	140~350	140~350
Drilling Depth(mm)	200	300	400	600
Walking Speed(Km/h)	2.5	2.5	2.5	2.5
Climbing Angles	30	30	30	30
Power(Kw)	65	84	95	115
Pressure(Mpa)	1.7~3.0	1.7~3.3	1.7~3.5	1.7~3.5
Air Consumption(m³/Min)	17~30	17~35	17~35	17~35
Drilling Pipe Diameter(mm)	76/89/102	89/102	76/89/102	76/89/102
Drilling Pipe Length(M)	1.5/2.0/3.0	1.5/2.0/3.0	1.5/2.0/3.0	1.5/2.0/3.0
Rig Lifting Force(T)	18	28	24	30
Swing Speed(Rpm)	50~70	55~115	45~115	45~115
Swing Torque(N.M)	5000~6500	7200~9500	8500~10000	8500~10500
Dimension(m)	3.8*1.7*2.35	5.5*1.95*2.78	5.2*2*2.78	5.4*2.1*2.85

Applications Of The Water Well Drilling Truck

The Water Well Drilling Truck is widely used across multiple sectors due to its flexibility, power, and ease of operation.

• Agricultural Irrigation Wells – Providing consistent water access in dry zones
• Municipal & Domestic Water Supply – Ensuring potable water for remote villages and homes
• Construction Sites – Supplying water for concrete mixing and dust suppression
• Mining and Industrial Sites – Supporting process water needs and dust control
• Disaster Relief & Emergency Response – Quickly delivering safe water where infrastructure is damaged

Its adaptability makes it a preferred solution in both developed and developing regions.

Features Of YG Water Well Drilling Truck

YG’s Water Well Drilling Truck is designed for rugged environments and long-term operation, with features that ensure performance and reliability.

• Truck-mounted chassis for excellent mobility and field access
• Hydraulic feed system for stable and smooth drilling
• Multiple drilling methods (rotary, DTH, mud pump) for different geological conditions
• Depth capacity ranging from 100m to over 600m, depending on the model
• Heavy-duty frame with high-load capacity and strong torque
• User-friendly controls and integrated safety systems

These features ensure that the operator can work efficiently and safely, even in challenging terrain.

Working Principle Of The Water Well Drilling Truck

The Water Well Drilling Truck functions by transferring engine power to the rig system mounted on the truck body. Depending on the soil condition, it may use rotary drilling with a drill bit or down-the-hole (DTH) hammer drilling for hard rock.

1. Position the truck and stabilize the rig using hydraulic outriggers.
2. Connect the drilling pipes and align the bit with the drilling point.
3. Engage the hydraulic power system to rotate or hammer the bit.
4. Pump water or drilling mud into the hole to remove debris.
5. Extend pipes as depth increases and monitor pressure and torque.
6. Once the target depth is reached, flush the hole and install the casing.

Advantages Of Truck-Mounted Borehole Drilling Rig

A truck-mounted borehole drilling rig offers unmatched advantages for drilling professionals who require mobility and reliability in the field. YG engineers its models to deliver high torque, precise control, and flexible drilling options, all mounted on a standard or heavy-duty truck base.

Benefits of truck-mounted rigs:

• Can access narrow or off-road sites
• Quick setup time, reducing idle hours
• Lower transportation costs compared to trailer or skid rigs
• Greater operator safety due to enclosed cab and remote control features
• Ideal for both shallow community wells and deep industrial boreholes

This system is perfect for companies seeking efficient, mobile water well drilling with fewer logistical complications.

Borehole Drilling Truck Price: What To Consider

When reviewing Borehole Drilling Truck Price, it’s important to understand what influences the total investment.

Key cost factors include:

• Drilling depth capacity – Deeper capabilities increase equipment cost
• Chassis type and engine power – Heavy-duty trucks add reliability but cost more
• Drilling method compatibility – Multi-functional rigs increase flexibility
• Hydraulic system and automation level – Better systems mean higher upfront costs
• Accessories and spare parts – Pumps, bits, and casing kits may be included

YG offers competitive pricing and customized solutions to fit different budgets without compromising quality or safety.

Operating Guide For Water Well Drilling Truck

Operating the Water Well Drilling Truck requires basic training and adherence to safety protocols.

1. Inspect and maintain rig components before use.
2. Stabilize the truck using outriggers and level it.
3. Set drilling parameters based on terrain and depth.
4. Engage the hydraulic systems and begin drilling.
5. Monitor water flow, vibration, and drill speed.
6. Clear the hole and install the well casing after reaching the depth.
7. Clean the equipment and perform maintenance after drilling.

Proper operation ensures both equipment longevity and drilling precision.

Why YG Manufacturer Stands Out in the Borehole Drilling Truck Price Market

When considering a Borehole Drilling Truck Price, YG Manufacturer offers a compelling combination of quality, performance, and value. Here’s why choosing us is a smart investment:

• High-Quality Manufacturing: We build our Water Well Drilling Trucks using premium-grade materials and advanced manufacturing techniques, ensuring durability and reliability in demanding environments.
• Competitive Pricing: We offer competitive pricing without compromising on the quality and performance of our rigs, providing excellent value for your investment.
• Customization Options: We understand that different projects have unique requirements. YG offers customization options to tailor our drilling trucks to your specific needs.
• Comprehensive Support: We provide comprehensive after-sales support, including technical assistance, spare parts availability, and training services.
• Industry Expertise: With years of experience in the drilling equipment industry, YG has a deep understanding of customer needs and delivers solutions that meet and exceed expectations.
• Focus on Innovation: We are committed to continuous innovation, constantly improving our designs and incorporating the latest technologies to enhance the efficiency and performance of our borehole drilling rig.

By choosing YG Manufacturer, you are not just purchasing a Water Well Drilling Truck; you are investing in a reliable partner committed to your success. Contact us today to learn more about our range of drilling solutions and find the perfect rig for your needs.
