The Wood Splitter Machine, also known as a wood log splitter machine, is a device designed to split large pieces of wood into smaller, more manageable pieces. Instead of manually swinging an axe or maul, a wood splitter applies a controlled force—either mechanical or hydraulic—to drive a wedge through the log, making wood processing significantly faster and easier. It simplifies the labor-intensive task of splitting wood by hand, saving time and effort.
WhatsApp/WeChat/Phone: 86 138 3715 9132
Wood Splitter Machine Parameter
| Max Splitting Force | 15T | 20T |
| Cycle Time | 7seconds | 8seconds |
| Max Splitting Length | 610mm | 610mm |
| Max Splitting Diameter | 380mm | 400mm |
| Work Efficiency | 4m3/h | 5m3/h |
| Power | 15HP gasoline engine | 15HP gasoline engine |
| Engine Displacement | 420cc | 420cc |
| Fuel Tank Capacity | 6.5L | 6.5L |
| Engine Oil Capacity | 1.1L | 1.1L |
| Gross Torque | 25N.m/2500rpm | 25N.m/2500rpm |
| Firewood Conveyor | Length:3.2m | Length:3.2m |
| Width of belt: 250 mm | Width of belt: 250 mm | |
| Width of chute: 400 mm | Width of chute: 400 mm | |
| Hydraulic rotator:1set | Hydraulic rotator:1set | |
| Chain Saw length | 1.2m | 1.2m |
| Chain Saw Rotate Speed | 5600rpm | 5600rpm |
| Sawing Speed | Adjustable | Adjustable |
| Oil Pump | 22GMP, 2-stage | 22GMP, 2-stage |
| Oil Tank Capacity | 50L | 50L |
| Control Valve | ONE-handle | ONE-handle |
| 4-Directional control valve | 4-Directional control valve | |
| Tyre | 12″ | 12″ |
| Knife | 4 ways (6 ways option) | 4 ways (6 ways option) |
| Weight | 480kg | 510kg |
| The Main Machine Package size | 2200*900*1100mm | 2200*900*1100mm |
| Conveyor Package Size | 2260*960*1170mm | 2260*960*1170mm |
Applications of Wood Splitter Machines
Wood splitter machines serve diverse sectors, enhancing efficiency in wood processing:
- Residential Use: Essential for homeowners preparing firewood for stoves/fireplaces, especially in cabins or off-grid settings, ensuring consistent log sizes for efficient heating.
- Commercial & Industrial: Timber companies and sawmills use heavy-duty models to process logs for lumber production, while furniture makers and carpenters rely on them for raw material preparation.
- Construction & Landscaping: Split wood is used in formwork, scaffolding, and decorative elements in construction, while landscaping benefits from wood chips for mulching, walkways, and fencing.
- Agriculture & Forestry: Farms use splitters for on-site wood stockpiling, heating, and fencing; forestry services employ mobile units for efficient log splitting in remote logging operations, reducing transportation costs.
- Rural & Off-Grid Living: Critical for year-round wood supply in areas without reliable electricity, providing self-sufficient heating and construction materials.
Features of Wood Splitter Machines
Wood splitter machines are defined by features that balance power, efficiency, and safety for diverse wood processing needs:
- Splitting Force (Tons): Ranges from 4 tons (electric models for softwoods) to 100+ tons (tractor-mounted units for dense hardwoods like oak), matching log size and type.
- Speed & Cycle Time: Hydraulic and kinetic models offer rapid cycles (2–15 seconds), ideal for high productivity, while manual/electric splitters are slower but suitable for light tasks.
- Power Source: Electric (quiet, low maintenance, 110V/220V), gas (portable, high power for remote sites), or PTO-driven (tractor-mounted for industrial use).
- Portability: Wheeled frames, tow hitches, or compact designs enable easy transport to job sites, with heavy-duty models prioritizing stability over mobility.
- Log Capacity: Handles logs up to 40+ cm in diameter (industrial) or 20 cm (residential), with vertical models reducing lifting effort for large logs.
- Safety Features: Include blade guards, two-hand operation, emergency stops, and automatic shut-offs to minimize accident risks.
- Durability: Steel frames with rust-resistant coatings ensure longevity, critical for frequent use in harsh outdoor environments.
Advantages of Using a Wood Splitter Machine
- Time – Saving: It can split wood much faster than manual methods, allowing you to prepare a large amount of firewood in a short time.
- Efficiency: The machine can split wood more evenly and precisely, ensuring that the split pieces are of a consistent size.
- Reduced Physical Strain: You don’t have to put in a lot of physical effort, which is especially beneficial for people with limited strength or mobility.
- Versatility: Splitters tackle logs that would resist axes, including twisted grain and knots.
Raw Materials That Can Be Processed
A Wood Splitter Machine can handle a variety of wood types. Hardwoods such as oak, maple, and hickory, which are dense and tough, can be split using a powerful splitter. Softwoods like pine, cedar, and fir are also easily processed. The machine can deal with logs of different sizes, from small branches to large tree trunks, depending on its capacity.
How to Choose a Wood Splitter Machine
Selecting a wood splitter requires balancing your needs with key features:
- Wood Type & Size: Match splitting force to log hardness (6–10 tons for softwoods like pine; 20+ tons for hardwoods like oak) and diameter (check max log size capacity).
- Usage Frequency: Opt for electric/manual models for occasional use; gas/hydraulic/kinetic for daily tasks; tractor-mounted for industrial-scale processing.
- Power Source: Electric (quiet, grid-accessible), gas (portable, off-grid), or PTO-driven (tractor-mounted for heavy-duty).
- Portability & Space: Choose wheeled/compact designs for mobility; prioritize stability for stationary industrial use.
- Budget & ROI: Manual splitters are affordable for light tasks, while hydraulic/kinetic models offer faster, durable performance for high-volume needs—invest in steel frames and safety features (guards, emergency stops) for longevity.
Wood Splitter Machine for Sale from YG
If you are in the market for a wood splitter machine for sale, YG offers a wide range of options. Their wood splitter for sale include manual, electric, hydraulic, and automatic models. YG’s machines are known for their high-quality construction, reliability, and safety features. Whether you are a homeowner looking for a simple electric wood splitter or a professional in need of a powerful hydraulic splitter, YG has a suitable product for you. With competitive prices and excellent customer service, YG is a great choice when purchasing a Wood Splitter Machine.
