What Is An Industrial Flake Ice Machine?
An industrial flake ice machine produces thin, dry, and low-temperature ice for cooling needs in many industries. Flake ice has a wide contact area and melts slowly, making it ideal for keeping food fresh, protecting product surfaces, and lowering the temperature quickly.
WhatsApp/WeChat/Phone: 86 138 3715 9132
Key Features Of An Industrial Flake Ice Machine
A modern industrial flake ice machine is designed for long working hours and harsh environments. Key features include:
- High-efficiency evaporator
- Stainless steel structure with strong corrosion resistance
- Continuous fast ice production
- Automatic operation with a smart control system
- Low-energy consumption cooling
- Optional air-cooled or water-cooled condenser
These features help keep ice clean, stable, and ready for industrial use.
Industrial Ice Making Equipment Parameters
Industrial flake ice machines are available in 3T, 5T, 8T, 10T, and 20T per day.
Below is the 10-ton model reference:
| Name | Specs |
| Design capacity | 10T/24h |
| Refrigeration capacity | 83.2kw |
| Evaporating temp. | -20℃ |
| Condensing temp. | 40℃ |
| Standard ambient temp | 25℃ |
| Standard water temp | 20℃ |
| Total input | 48.84KW |
| Compressor power | 44.7KW |
| Reducer power | 0.75KW |
| Water pump power | 0.37KW |
| Brine water pump power | 0.18 KW |
| Air condenser fan power | 2.84KW |
| Power supply | 3P-380V-50Hz |
| Water pressure | 0.1Mpa－0.5Mpa |
| Refrigerant | R404A |
| Ice temp. | -5℃ |
| Ice thickness | 1.5mm-2.2mm |
| Water consumption（M3/h） | 0.42 |
| Dia. of the water inlet pipe | (2*3/4″) 1/2″ |
| Machine net weight | Approx 2000KG |
| Machine size（L*W*H） | 2680×1800×1850mm |
| Air condenser size（L*W*H） | 3200x1050x1100mm |
This capacity fits seafood plants, large markets, chemical cooling lines, and concrete stations.
Applications Of A Commercial Flake Ice Maker
A commercial flake ice maker supports many industries with stable cooling performance:
- Fishery cooling and fishing vessel ice supply
- Fresh fruit and vegetable preservation
- Seafood and meat processing plants
- Food packaging workshops
- Chemical and dye cooling lines
- Concrete mixing temperature reduction
Thin flake ice protects product structure and maintains freshness for long periods.
Why Choose A Large-Capacity Flake Ice Machine?
A large capacity flake ice machine is designed for heavy-duty industrial use. It offers:
- Higher daily ice output for big factories
- Support for 24-hour continuous working
- Easy integration with automatic ice storage systems
- Ideal for ports, seafood centers, and concrete batching plants
This type provides stable cooling efficiency and meets large-scale production demands.
3 Real Cases Using Flake Ice Machines
Industrial flake ice machines are widely used in global fisheries. Here are three typical cases:
Deep-Sea Catch Cooling
Flake ice quickly lowers fish temperature after capture, protecting meat quality.
Fish Structure Preservation
Thin ice does not damage the fish surface, helping maintain texture during transportation.
Boat and Dock Use
Machines support both onboard installation and dockside supply systems. They can work with automatic ice delivery equipment.
How To Choose The Right Industrial Flake Ice Machine
Before buying, consider the following points:
- Daily ice output needs
- Installation location (indoor/outdoor)
- Available voltage and cooling conditions
- Whether cold storage is required
- Budget and long-term running cost
- Cooling type (water-cooled or air-cooled)
These factors help you choose a machine that fits your actual industry needs.
Frequently Asked Questions
1. How long can flake ice last?
Flake ice melts slowly and can last many hours in an insulated bin.
2. What refrigerant is used?
Most units use R404A or R507 for stable cooling and global compliance.
3. Can the machine run 24 hours?
Yes, it is designed for long-time continuous operation.
4. Should I choose air-cooled or water-cooled?
Air-cooled fits dry or outdoor sites; water-cooled offers higher efficiency.
5. What power supply do I need?
Common options are 380V/50Hz or 220V/60Hz. Customization is available.
6. What is the ice thickness?
Typical thickness is 1.5–2.2 mm for fast cooling.
7. Is installation easy?
Yes. Machines arrive pre-assembled and require simple connection.
8. Can it be used on fishing boats?
Yes, many models fit vessel use for deep-sea cooling.
9. What is the service life?
With proper maintenance, 8–12 years or more.
10. Does YG provide after-sales support?
YG offers full technical support, spare parts, and installation guidance.
