What Is A Stirrup Bending Machine?
A Stirrup Bending Machine bends steel bars into closed or open square shapes called stirrups. These stirrups hold concrete and rebar together inside beams and columns. They are crucial for building strong concrete structures.
Unlike normal benders, this machine can automatically measure and cut rebar to the right size before bending it into shape.
WhatsApp/WeChat/Phone: 86 138 3715 9132
Stirrup Bending Machine Parameter
| Model | YG-1 | YG-2 | YG-3 | YG-4 |
| Single wire(mm) | Round steel 4-10mmDeformed steel bar 4-8mm | Round steel 4-12mmDeformed steel bar 4-10mm | Round steel 5-14mmDeformed steel bar 5-12mm | Round steel 4-12mmDeformed steel bar 4-10mm |
| Double wire(mm) | Round steel 4-6mmDeformed steel bar 4-6mm | Round steel 4-8mmDeformed steel bar4-8mm | Round steel 5-10mmDeformed steel bar 5-10mm | Round steel 4-8mmDeformed steel bar 4-8mm |
| Max bending angle | ±180° | ±180° | ±180° | ±180° |
| Center pin diameter | 16、18、20 | 16、18、20 | / | 16、18、20 |
| Maximum towing speed | 60m/min | 60m/min | 110m/min | 110m/min |
| Maximum bending speed | 800°/sec | 800°/sec | 1000°/sec | 800°/sec |
| Machine size | 2600*800*1700mm | 3280*1000*1700mm | 3850*1200*2200mm | 3660*1110*1700mm |
| Device color | Yellow(customized) | Yellow(customized) | Yellow(customized) | Yellow(customized) |
| Pieces Processed | ≤2 | ≤2 | ≤2 | ≤2 |
| Air circuit system pressure | ≥0.8mpa | ≥0.8mpa | / | ≥0.8mpa |
| Total Power | 14kw | 20kw | 32kw | 23.5kw |
| Working temperature | -5°C~40° | -5°C~40° | -5°C~40° | -5°C~40° |
| Length accuracy | ±1mm | ±1mm | ±1mm | ±1mm |
| Angle accuracy | ±1° | ±1° | ±1° | ±1° |
| Average power | 4.5KW/h | 5KW/h | 5KW/h | 5KW/h |
| Total weight | 1150KG | 1350KG | 2200KG | 1550KG |
Features Of Automatic Stirrup Bender
The Automatic Stirrup Bender has many helpful features for fast and precise work:
- Digital Control System: Input sizes and angles for quick changes.
- Automatic Feeding and Cutting: Machine pulls in rebar, cuts, then bends.
- High-Speed Operation: Makes hundreds of stirrups per hour.
- Shape Memory: Stores many shapes for different projects.
- Strong Blades: Last longer and cut cleanly.
- Compact Size: Fits in smaller workshops or mobile trailers.
These features save time and reduce mistakes.
Shapes You Can Create With Tubing Benders
Though many people link tubing benders with round pipes, a stirrup bender creates various shapes:
- Square stirrups for columns
- Rectangular stirrups for beams
- Triangular stirrups for special designs
- Custom bends for unique projects
This machine helps builders keep shapes consistent and accurate.
Advantages Over Manual Bending Methods
Compared with manual bending, a steel bending machine offers:
- Faster production for big projects
- Consistent shape and size every time
- Less waste of steel materials
- Reduced labor costs
- Lower risk of worker injury
This makes it a smart investment for contractors.
Applications Of Stirrup Benders In Construction
A stirrup bending machine is used in:
- Building construction for beams and columns
- Bridge projects needing heavy steel cages
- Prefab concrete plants for ready-made steel cages
- Housing projects for fast stirrup production
These machines ensure strong and safe buildings.
How To Choose A Stirrup Bender
When buying a stirrup bender, check:
- The bar diameter can be bent
- Machine speed (pieces per hour)
- Digital memory for shapes
- Blade quality and lifespan
- Machine size and weight for your workspace
Choosing the right machine saves you time and costs.
Stirrup Bending Machine Price Guide
The stirrup bending machine price depends on:
- Bending capacity and bar size
- Speed and level of automation
- Extra features like shape memory
- Electric or hydraulic drive
- Brand and spare part availability
YG Machinery offers factory prices and technical support for all machines.
YG Machinery’s Service For Stirrup Benders
To help customers use their Automatic Stirrup Bender, YG offers:
- One-year warranty
- Fast shipping for replacement parts
- English manuals and video guides
- Remote technical support
- Custom machine solutions
These services make sure your projects keep moving.
WhatsApp/WeChat/Phone: 86 138 3715 9132
